PPGI PPGL coil
| Products name | PPGL PPGI |
|---|---|
| Thickness range | 0.125mm to 4.0mm |
| Common thickness | 0.15mm, 0.2mm, 0.25mm, 0.3mm, 0.35mm, 0.4mm, 0.45mm, 0.5mm, 0.55mm |
| Width range | 600-1500mm |
| Common width | 914mm, 1000mm, 1219mm, 1200mm, 1220mm |
| Zinc coating | 20g/m2 - 275g/m2 |
| Surface treatment | Chromated and oiled, anti-fingerprint |
| Coil weight | 3-8MT, according to the customer's request |
| Hardness | Softy , half hard and hard quality |
| Popular RAL color | RAL7024, RAL7016, RAL7026 |
| Application | Construction, roofing, windows, Automotive uses, home appliances |
| Gauge (Ga) | Mild steel (Inch) | Galvanized Steel (Inch) | Aluminum (Inch) | Mild steel (mm) | Galvanized Steel (mm) | Aluminum (mm) |
|---|---|---|---|---|---|---|
| 3 | 0.2391 | 0.2294 | 6.0731 | 5.8268 | ||
| 4 | 0.2242 | 0.2043 | 5.6947 | 5.1892 | ||
| 5 | 0.2092 | 0.1819 | 5.3137 | 4.6203 | ||
| 6 | 0.1943 | 0.162 | 4.9352 | 4.1148 | ||
| 7 | 0.1793 | 0.1443 | 4.5542 | 3.6652 | ||
| 8 | 0.1644 | 0.1681 | 0.1285 | 4.1758 | 4.27 | 3.2639 |
| 9 | 0.1495 | 0.1532 | 0.1144 | 3.7973 | 3.8913 | 2.9058 |
| 10 | 0.1345 | 0.1382 | 0.1019 | 3.4163 | 3.5103 | 2.5883 |
| 11 | 0.1196 | 0.1233 | 0.0907 | 3.0378 | 3.1318 | 2.3038 |
| 12 | 0.1046 | 0.1084 | 0.0808 | 2.6568 | 2.7534 | 2.0523 |
| 13 | 0.0897 | 0.0934 | 0.072 | 2.2784 | 2.3724 | 1.8288 |
| 14 | 0.0747 | 0.0785 | 0.0641 | 1.8974 | 1.9939 | 1.6281 |
| 15 | 0.0673 | 0.071 | 0.0571 | 1.7094 | 1.8034 | 1.4503 |
| 16 | 0.0598 | 0.0635 | 0.0508 | 1.5189 | 1.6129 | 1.2903 |
| 17 | 0.0538 | 0.0575 | 0.0453 | 1.3665 | 1.4605 | 1.1506 |
| 18 | 0.0478 | 0.0516 | 0.0403 | 1.2141 | 1.3106 | 1.0236 |
| 19 | 0.0418 | 0.0456 | 0.0359 | 1.0617 | 1.1582 | 0.9119 |
| 20 | 0.0418 | 0.0396 | 0.032 | 0.9119 | 1.0058 | 0.8128 |
| 21 | 0.0329 | 0.0366 | 0.0285 | 0.8357 | 0.9296 | 0.7239 |
| 22 | 0.0299 | 0.0336 | 0.0253 | 0.7392 | 0.8531 | 0.6426 |
| 23 | 0.0269 | 0.0306 | 0.0226 | 0.6833 | 0.7772 | 0.574 |
| 24 | 0.0239 | 0.0276 | 0.0201 | 0.6071 | 0.7004 | 0.5105 |
| 25 | 0.0209 | 0.0247 | 0.0179 | 0.5309 | 0.6274 | 0.4547 |
| 26 | 0.0179 | 0.0217 | 0.0159 | 0.4547 | 0.5512 | 0.4039 |
| 27 | 0.0164 | 0.0202 | 0.0142 | 0.4166 | 0.5131 | 0.3607 |
| 28 | 0.0149 | 0.0187 | 0.0126 | 0.3785 | 0.475 | 0.32 |
| 29 | 0.035 | 0.0172 | 0.0113 | 0.3429 | 0.4369 | 0.287 |
| 30 | 0.012 | 0.0157 | 0.01 | 0.3048 | 0.3988 | 0.254 |
| 31 | 0.0105 | 0.0142 | 0.0089 | 0.2667 | 0.3607 | 0.2261 |
| 32 | 0.0097 | 0.0134 | 0.008 | 0.2464 | 0.3404 | 0.2032 |
| 33 | 0.009 | 0.0071 | 0.2286 | 0.1803 | ||
| 34 | 0.0082 | 0.0063 | 0.2083 | 0.16 | ||
| 35 | 0.0075 | 0.0056 | 0.1905 | 0.1422 | ||
| 36 | 0.0067 | 0.1702 |
